UCC27425DRG4 Datasheet, PDF

Electronic Manufacturer	Part no	Datasheet	Electronics Description
Texas Instruments	UCC27425DRG4		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers With Enable
	UCC27425DRG4		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers With Enable
	UCC27425DRG4		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers
Texas Instruments	UCC27425DG4		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers With Enable
	UCC27425DG4		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers With Enable
	UCC27425DG4		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers
	UCC27425DGN		[Old version datasheet] DUAL 4-A HIGH SPEED LOW SIDE MOSFET DRIVERS WITH ENABLE
	UCC27425DGN		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers With Enable
	UCC27425DGN		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers With Enable
	UCC27425DGN		[Old version datasheet] Dual 4-A High Speed Low-Side MOSFET Drivers

Product Overview

Digi-Key Part Number	296-38319-1-ND
Quantity Available	0 Factory Stock : 10,001
Manufacturer	Texas Instruments
Manufacturer Part Number	UCC27425DR
Description	IC MOSFET DRIVR DUAL HS 4A 8SOIC
Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	6 Weeks
Detailed Description	Low-Side Gate Driver IC Inverting, Non-Inverting 8-SOIC

Documents & Media

Datasheets	UCC2742x Series
Featured Product	Power Management
Manufacturer Product Page	UCC27425DR Specifications
EDA / CAD Models	Download from Ultra Librarian
Online Catalog	Low-Side

Product Attributes	Select All
Categories	Integrated Circuits (ICs)
Categories	PMIC - Gate Drivers
Manufacturer	Texas Instruments
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Driven Configuration	Low-Side
Channel Type	Independent
Number of Drivers	2
Gate Type	N-Channel, P-Channel MOSFET
Voltage - Supply	4 V ~ 15 V
Logic Voltage - VIL, VIH	1V, 2V
Current - Peak Output (Source, Sink)	4A, 4A
Input Type	Inverting, Non-Inverting
Rise / Fall Time (Typ)	20ns, 15ns
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOIC

Part no.	UCC27425DRG4
Packge/Case	8-SOIC
Manutacturer	Texas Instruments
Date Code	17+
Description	电桥驱动器IC MOSFET DRIVR DUAL HS 4A 8SOIC
Datasheet	Check Datasheet
