DRV8833RTYR  IC MOTOR DRIVER PAR 16QFN
  |  1 orders
Shipping
-->Arrival time 5-7 days
---->Arrival time 15-27 days
-->Arrival time 5-7 days
Quantity
 PCS
Parts Amount
US $0.00

Choose us! Escort for your needs!!!^_^
Product Details
Part no.DRV8833RTYR
Packge/Case16-QFN (4x4)
ManutacturerTexas Instruments
DescriptionIC MOTOR DRIVER PAR 16QFN
 DatasheetCheck Datasheet

Texas Instruments DRV8833RTYR

The DRV8833 device provides a dual bridge motor driver solution for toys, printers, and other mechatronic applications.

The device has two H-bridge drivers, and can drive two DC brush motors, a bipolar stepper motor, solenoids, or other inductive loads.

The output driver block of each H-bridge consists of N-channel power MOSFETs configured as an H-bridge to drive the motor windings. Each H-bridge includes circuitry to regulate or limit the winding current.

Internal shutdown functions with a fault output pin are provided for overcurrent protection, short-circuit protection, undervoltage lockout, and overtemperature. A low-power sleep mode is also provided.

The DRV8833 is packaged in a 16-pin WQFN package with PowerPAD™ (Eco-friendly: RoHS & no Sb/Br).

德克萨斯仪器drv8833rtyr
的drv8833设备提供玩具、打印机双桥电机驱动器解决方案,和其他机电一体化应用。
该装置具有两个H桥驱动器,可以驱动两个直流有刷电机、双极性步进电机,电磁阀,或其他感性负载。
每个H桥的输出驱动器块由N沟道功率MOSFET配置为H桥驱动电机绕组。每个H桥包括调节或限制绕组电流的电路。
内部有故障输出引脚关机功能提供了过流保护、短路保护、欠压保护、超温。还提供了一种低功耗睡眠模式。
的drv8833是封装在一个16引脚WQFN封装(PowerPAD™生态友好:RoHS及无锑/溴)。
